SPECIFICATIONS |
|
| Content | 100% Recycled Polyester |
| Width | 167 cm (66") |
| Weight | 496 g/m |
| Cleaning | Code "WS" Care |
| Application |
Vertical Surface, Acoustic Panel
|
TESTING |
|
| Crocking | AATCC 8 Wet: Class 3.0, Dry: Class 4.0 |
| Light Fastness | AATCC 16.3 Class 4.0 at 40 hours |
| Tensile Strength | ASTM D 5034 Warp: 250.0 lbs / 113.6 kgs, Weft: 150.0 lbs / 68.2 kgs |
| Tearing Strength | ASTM D 2261 Warp: 20.0 lbs / 9.1 kgs, Weft: 30.0 lbs / 13.6 kgs |
| Flammability (Vertical) | ASTM E84 Class 1 or A |
ACOUSTIC PERFORMANCE
This graph shows the acoustic transparency of the fabric. The plot below summarizes impedance chamber measurements of absorption of an anechoic termination and the fabric in front of the anechoic termination.
KUDOS
4350-N01-01
